NTSA82 motor soft starter is a new type of motor starting and protection that combines power electronic technology, microprocessor and automatic control device. It can start/stop the motor smoothly without step, avoiding the transmission caused by the use of direct starting , star/delta starting, auto-coupling decompression starting, etc. It can effectively reduce the starting current and power distribution capacity, avoid the mechanical and electrical shocks caused by starting the motor in the conventional starting method, and avoid Free capacity investment. At the same time, the 6NTMX soft starter integrates current transformers and contactors inside, and users do not need to connect externally.

More information

Request manual
