NTFA81 series inverter is an open-loop vector control inverter, its features:

This model has a wide range of applications;

Support wall-mounted, embedded, side-by-side, top-bottom and other installation methods;

132KG/160KP and above models have built-in DC reactor;

Flexible application function expansion, mainly including IO expansion card, PLC expansion card;

Rich communication expansion, CANopen, Profibus, EtherCAT and other communication expan sion cards can be connected through the expansion interface;

External LED operation keyboard can be introduced;

All series support common DC bus and DC power supply.
