The NTQV81 Static Var Compensator is designed for rapid and effective dynamic reactive power compensation under fluctuating loads across various operating conditions. It significantly improves power factor while compensating for voltage fluctuations and flicker, load imbalance, and harmonics. This effectively enhances power quality, delivers substantial energy savings and reduced consumption, thereby ensuring the safe, stable, efficient, and high-quality operation of power systems.

Product Features:

Modular design with compact size and large capacity facilitates installation and maintenance, reduces floor space requirements, and lowers product and construction costs.
Can be installed in parallel for easy capacity expansion. Features fast response speed, enabling phase-by-phase stepless regulation and generating bidirectional reactive current.
Fault Self-Diagnosis Function
RS485 communication interface, supporting remote communication while enabling telemetry, telecontrol, and teleindication functions.
Supports control switching of three-phase and single-phase capacitor banks
Comprehensive event logging with non-volatile storage, supporting up to 500 events;
Selective or combined compensation of reactive power, harmonic filtering, and three-phase unbalance mitigation based on load characteristics;
Overcurrent and overvoltage protection, harmonic and inrush current limit alarms and protection. After restoration to normal conditions, the product automatically resumes operation.
