Main features of the product
The solid sealed pole adopts advanced APG process technology
Adopting an integrated design of the operating mechanism and the circuit breaker body, it can be used as a fixed installation unit or combined with a dedicated propulsion mechanism to form a handcart unit
The operating mechanism is a flat spring energy storage mechanism with manual and electric energy storage functions. The energy storage and closing of the operating mechanism are divided into units using a single functional unit module, making its structure compact
The temperature induction coil that can be pre installed on the contact arm of the circuit breaker enables online measurement and monitoring of the temperature rise of the contact
Can install circuit breaker electric operation unit propulsion mechanism device
Technical parameter
| Serial number | Name | Unit | Main technical parameters | |||||
| 1 | Rated voltage | kV | 12 | |||||
| 2 | Rated short-time power frequency withstand voltage (1min) | 42 (relative/phase to phase)/48 (fracture) | ||||||
| 3 | Rated lightning impulse withstand voltage (peak) | 75 (relative/phase to phase)/85 (fracture) | ||||||
| 4 | Rated frequency | Hz | 630 | 630 | 630 | 1250 | 1600 | |
| 5 | Rated current | A | 1250 | 1250 | 1250 |
1600 |
2000 | |
| 1600 | 2000 | 2500 | ||||||
| 2000 | 2500 | 3150 | ||||||
| 2500 | 3150 | 4000 | ||||||
| 3150 | 4000 | |||||||
| 6 | Rated short-circuit breaking current | kA | 20 | 25 | 31.5 | 40 | 50 | |
| 7 | Rated short-time withstand current | 20 | 25 | 31.5 | 40 | 50 | ||
| 8 | Rated short-circuit duration | s |
4 |
|||||
| 9 | Rated peak withstand current | kA | 50 | 63 | 80 | 100 | 125 | |
| 10 | Rated short-circuit closing current | 50 | 63 | 80 | 100 | 125 | ||
| 11 | Mechanical lifespan | 次 | 30000 (10000 times for 50kA) | |||||
